Smart Upper Arm Blood Pressure Monitor (Large Cuff)
Precision You Can Trust, Comfort You Deserve.
Introducing the
Smart Upper Arm Blood Pressure Monitor (Large Cuff)
The FondCircle FBP-A3XL Upper Arm Blood Pressure Monitor is a reliable and user-friendly device designed for accurate and efficient cardiovascular monitoring. Utilizing advanced oscillometric technology, it displays systolic and diastolic blood pressure readings, along with pulse rate values ranging from 40 to 199 bpm. The monitor features irregular pulse rate detection to help identify potential arrhythmias, as well as automated cuff wrap detection and excessive body motion detection, ensuring optimal placement and minimal interference during measurements. To improve reliability, it offers a triple measurement averaging function, delivering a more precise reading by calculating the average of three consecutive results.
Engineered for both clinical and home environments, the FBP-A3XL supports multiple patient use and accommodates a wide range of arm sizes with its 40–52 cm cuff. It operates on either four AAA batteries or a DC 5V USB-C power source for versatile use. The device is equipped with a large digital LCD display (60.5 x 92.5 mm) housed in a compact and lightweight design (140 x 130 x 50 mm, approx. 275 g excluding batteries and cuff). It functions accurately within a pressure range of 0–299 mmHg, with measurement precision of ±3 mmHg for pressure and ±5% for pulse readings. Designed to withstand diverse conditions, the monitor remains stable across a wide range of temperatures and humidity levels, making it a dependable tool for consistent and accurate blood pressure monitoring.
TRIPLE MEASUREMENT AVERAGING FOR GREATER ACCURACY
The FBP-A3XL enhances measurement reliability with its Triple Measurement Averaging feature. Instead of relying on a single reading, the device automatically takes three consecutive measurements and calculates the average. This reduces the impact of temporary fluctuations or movement-related errors, giving users a more stable and accurate representation of their blood pressure.
ADVANCED DETECTION FOR SAFER MONITORING
Equipped with intelligent monitoring technology, the device includes Irregular Pulse Rate Detection, Automated Cuff Wrap Detection, and Excessive Body Motion Detection. These features help identify potential health concerns like arrhythmias and ensure that the cuff is properly positioned. They also alert users to any body movement that may compromise the reading, resulting in safer and more trustworthy measurements.
LARGE, HIGH-VISIBILITY LCD DISPLAY
The monitor features a spacious 60.5 x 92.5 mm LCD screen that clearly displays systolic and diastolic blood pressure along with pulse rate data. This large, easy-to-read interface enhances usability, particularly for older adults or users with vision challenges, by reducing the risk of reading errors and improving user confidence in the results.
Specs
- Measuring Method: Oscillometric
- Measurement Range: Cuff Pressure: 0-299 mmHg
- SYS: 60-230 mmHg
- DIA: 40-130 mmHg
- Pulse Value: 40-199 bpm - Measurement Accuracy:
- Pressure value: ±3 mmHg (±0.4kPa)
- Pulse Value: ±5 bpm - Power Source: 4 AA batteries or (DC 5V) USB Type-C Cable
- Operating conditions:
- Temperature: 5-40ºC (41-104°F)
- Humidity: 15-95% RH, non-condensing
- Atmospheric pressure: 50-106 kPa - Storage and Transportation Conditions:
- Avoid strong impact, direct impact, and exposure to rain
- Avoid corrosive gas
- Keep in a well-ventilated area
- Temperature: -20-60ºC (-4-140°F)
- Humidity: 0-93% RH, non-condensing
- Atmospheric pressure: 50-106 kPa - Display: LCD
- Cuff Size: 40-52 cm
- Device Dimensions: 140x130x50 mm
- LCD Size: 60.5x92.5 mm
- Weight: Approx. 275 g (excluding batteries and cuff)
- Type of Use: Multiple Patient Use
